Uni-T Cost-effective Thermal Camera UTi712S
Technical Data
Certificates: CE, UKCA, FCC, RoHS
IR resolution (Pixels): 120×90
Display: 2.4” TFT LCD (320×240)
Field of view (FOV): 50°×38°
Thermal sensitivity(NETD): ≤60mK
Spatial resolution (IFOV): 7.3mrad
Frame rate: ≤25Hz
Spectral range: 8~14µm
Focus: Focus free
Temperature measurement range: -20℃~400℃
Accuracy: ±2℃ or ±2% whichever is greater
Emissivity: 0.01~1.00 adjustable (0.95 default)
Battery: Fixed Li-ion battery (3.7V 2600mAh)
Battery operation time: ≥8 hours
USB: Type-C
Storage: 16GB Micro SD card
Image/Video storage format: BMP
Product size: 197 ×72 ×60mm
Product net weight: 310g
Scope of Delivery
• 1 x Uni-T Cost-effective Thermal Camera UTi712S• 1 x Hand strap
• 1 x Micro SD card
• 1 x Type-C USB cable
• 1 x English manual
• 1 x Documents download operation guide card
12 Months UNI-T Warranty
Category:
RM 885.00
Availability:
In Stock
