Fluid Film Powerful Rust & Corrosion Protection
Chemical Product - Fluid Film Powerful Rust & Corrosion Protection
FLUID FILM® is a penetrant and lubricant also used for corrosion prevention. It is a non-toxic, long lasting, thixotropic liquid that has been used for over fifty years in the highly corrosive marine environment of ships and offshore drilling rigs. More recently they have been introduced and successfully utilized in the aerospace, aircraft and automobile industries as well as for home maintenance. Facilities where they are used include the following: government facilities, commercial fishing concerns, gas companies, agriculture, salt plants, municipal plants, power plants, manufacturing plants and pulp and paper mills.
FLUID FILM® is formulated from specially processed wool-wax, highly refined petroleum oils and selected agents to provide corrosion control, penetration, metal wetting and water displacement. The long lasting product contains no solvents, will not dry out and will penetrate to the base of all metals, providing corrosion protection from both natural and industrial atmospheres. Heavily corroded and/or frozen parts such as nuts, bolts, shafts, etc. that would normally be damaged during maintenance, can be salvaged by applying FLUID FILM®.
Unless designated otherwise, the following data refers to FLUID FILM® NAS or FLUID FILM® AS after the propellant has evaporated away following spray application.
| Appearance |
Clear, straw colored liquid. |
| Viscosity |
Brookfield - HBF, 70 ° F
#2 Spindle - at 2 RPM
10.5-13.5 reading - 16,800 - 21,600 cps |
Flash Point, Bulk Liquid
(ASTM-92 Cleveland Open Cup) |
405°F minimum. |
| Non-Volatile |
89% minimum (3 hours @ 220°F). |
VOC.
(CARB 310) |
AS: Less than 25%,
NAS: Less than 1% |
| Specific Conductivity |
Less than 10 -9 ohm/cm @ 1 mHz. |
| Specific Gravity |
0.875 - 0.885 (less propellant). |
Effect on Rubber
(ASTM D-471 @ ± 158°F 70 hours) |
None on neoprene and buna-n. May cause swelling on non oil-resistant rubber goods. |
| Effect on Paint |
None on most painted surfaces. |
| Effect on Aluminum |
No pitting. |
Extreme Pressure
(ASTM D-2782 Timken Method) |
Fail load - 15 pounds. |
Wear Prevention - Characteristics
(ASTM D-2266 Four Ball Method) |
40 Kg., 1200 RPM for 1 hour @ 167°F. Results: Scar diameter of 0.49mm. |
| Repaintability |
Contain no silicones. It is recommended that surfaces treated with FLUID FILM® AS or NAS be hot water or steam detergent washed (120°F), whichever is most effective. |
Corrosion Protection
(ASTM D-1735 Humidity Cabinet) |
Passes 50 days. |
ASTM D-1748
(Humidity Cabinet) |
Passes 30 days. |
MIL-C-16173
(Corrision Requirment) |
Grade 2 -Soft Films. Meets & exceeds salt spray requirements. |
| Water Replacement |
Displaces water from all metal surfaces (MIL-C-23411,Paragraph 3.6). |
| Toxicity |
Non-toxic, LD-50 greater than 3 grams per kilogram. Non-irritating skin response. Very slight irritation to the eyes. (Toxicity tests performed according to standard methods by an independent laboratory). |
| Warning |
AS: Extremely flammable. Contents under pressure. Do not puncture, incinerate or store above 120°F. Keep from open flame.
NAS: Combustible. Do not incinerate |
| Spray Nozzle Cleaning |
Turn can upside down, point in a safe direction and spray until only propellant escapes. If spray button becomes clogged during use, pull it from the can and clean it with a fine wire or needle. Replace the button with a gentle twisting motion, keeping it pointed in a safe direction. Do not stick pins or other objects into nozzle tube. |
